tpaintbox

[Properties (by Name)] [Methods (by Name)]

Widget dedicated to custom drawing

Declaration

Source position: msesimplewidgets.pas line 746

type tpaintbox = class(tscrollbox)

published

property font: twidgetfont; [rws]

property onbeforepaint: painteventty;

property onpaintbackground: painteventty;

property onpaint: painteventty;

property onafterpaint: painteventty;

property onmouseevent: mouseeventty;

property onchildmouseevent: mouseeventty;

property onclientmouseevent: mouseeventty;

property onmousewheelevent: mousewheeleventty;

property onkeydown: keyeventty;

property onkeyup: keyeventty;

property onshortcut: shortcuteventty;

property onresize: notifyeventty;

property onmove: notifyeventty;

end;

Inheritance

`tpaintbox`		Widget dedicated to custom drawing
\|
`tscrollbox`
\|
`tscalingwidget`
\|
`tcustomscalingwidget`
\|
`tpublishedwidget`
\|
`tpublishedwidgetnwr`
\|
`tactionpublishedwidgetnwr`
\|
`tactionwidget`
\|
`twidget`
\|
`tactcomponent,iscrollframe,iface,iassistiveclient`
\|
`tmsecomponent,iactivatorclient`		Extends the FPC tcomponent with object linking facilities and the like; base of every MSEgui component
\|
`tcomponent,ievent,iificommand,iificlient`
\|
`tpersistent`
\|
`TObject`

Description

Widget dedicated to custom drawing: fill its onpaint event with drawing instructions on the acanvas: tcanvas parameter, as in the following example, which fills the background, draws a shaded ellipse, a diagonal line and a few points.

uses
  main_mfm;

procedure tmainfo.paintbox1_paint(const sender: twidget;
               const acanvas: tcanvas);
var
  x: integer;
begin
  acanvas.fillrect(makerect(0, 0, sender.bounds_cx, sender.bounds_cy), cl_ltgray);

  acanvas.fillellipse(makerect(sender.bounds_cx div 2, sender.bounds_cy div 2, 100, 100), cl_gray, cl_dkgray);

  acanvas.drawline(
    makepoint(0, 0),
    makepoint(sender.bounds_cx, sender.bounds_cy),
    cl_yellow
  );

  for x := 0 to 9 do
    acanvas.drawpoint(makepoint(x, 0), cl_magenta);
end;
